Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrop looms manufactured by Draper Company, Hopedale, Mass., U.S.A (1905)

Draper, George Otis, 1867-1923, Draper Company · [Hopedale, Mass. : Draper Company] · leaf 67

An illustration from Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrop looms manufactured by Draper Company, Hopedale, Mass., U.S.A, 1905, leaf 67
STEEL HARNESS KNOCK-OFF. This cut illustrates a harnesswarp stop-motion as used on someof our looms. The vibrators arerocked from a cam movement onthe lower shaft ami the trip actsdirectly on the shipper. 65 WARP STOP-MOTIONS. At the start of our loom introduction, we limited ourselvesto the…

Looms · Weaving
