Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrop looms manufactured by Draper Company, Hopedale, Mass., U.S.A (1905)

Draper, George Otis, 1867-1923, Draper Company · [Hopedale, Mass. : Draper Company] · leaf 74

An illustration from Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrop looms manufactured by Draper Company, Hopedale, Mass., U.S.A, 1905, leaf 74 — le itself. Like theAumann feeler, on the opposite page, it is independent ofback lash in lay and position of front plate. The operatingparts are shown in full relief, and are few in number. Thecuts of the Aumann feeler show the pattern in use just previous.The mechanism at this side end of the… … AIM ANN FEELER JUST BEFORE OPERATION. This cut shows the form of feeler mechanism devised byMr. Louis A. Aumann, agent of the Dwight Mfg. Co. at Chic-opee and modified by inventions of W. F. and C. II. Draper.

Looms · Weaving

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
