Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrup looms manufactured by Draper company, Hopedale, Mass., U. S. A. (1904)

Draper, George Otis, 1867-1923 · Milford, Mass. : Printed by Cook & sons · leaf 78

An illustration from Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrup looms manufactured by Draper company, Hopedale, Mass., U. S. A., 1904, leaf 78
e itself. Like theAumann feeler, on the opposite page, it is independent ofback lash in lay and position of front plate. The operatingparts are shown in full relief, and are few in number. Thecuts of the Aumann feeler show the pattern in use just previous.The mechanism at this side end of the loom,… … AU^vIAXX FEELER JUST BEFORE OPERATION. This cut shows tlie form of feeler mechanism devised byMr. Louis A. Ainiiann, a<i:ent of the Dwis^ht Mfof. Co. at Chic-opee and modified by inventions of \V. F. and C. FL Draper.

Looms
