ement is the fraction e b — of the total eccentric travel and there-at fore, while the eccentric is moving through this amount, the steam pin is moving through the same fraction of the distance a g, Fig. 8. We have already found that d lies on the line Oj, which gives the latest point of cut-off… … 42 cut-of ratio. We have already found that the steam valve must be at the lead opening when the eccentric is at d. Therefore, when the steam valve is open by the lead, the steam pin must be at the point e9 Fig. 8, where ag is the total e amotion of the steam pin and —— is ag equal to the latest…
