Hartford Steam Boiler Inspection and Insurance Company · Hartford, Ct. : Hartford Steam Boiler Inspection and Insurance Co · leaf 105
facts that heating surface, in order that it may act as such, must have fire in contact withone side and water in contact with the other, and that it is simply impossible to super-heat steam when it is in contact with the large surface of water ordinarily presented bythe disengaging surface of a… … Fig. 2. Our illustrations this month show the principles embodied in some of these settingswhich have been most extensively used. We publish them that our patrons may know what to avoid. . ■, ■ ^i . ,i Fic-ure 1 is a transverse section of a boiler and setting showing the most usualmethocl of…
Locomotives · Steam-boiler explosions
