Hartford Steam Boiler Inspection and Insurance Company · Hartford, Ct. : Hartford Steam Boiler Inspection and Insurance Co · leaf 152
ted butt-strap boiler joint, in accordance v^ith the Philadelphiarule, an example of .such a calculation will be interesting and is here given. The Phila-delphia law says that, in estimating the strength of the longitudinal riveted seams inboilers, the following two formulae shall be applied:… … A Triple-Riveted Bltt-Stkap Joint. result is the percentage of the strength of the net section of the sheet at the seam, ascompared with the strength of the solid part of the same sheet. Formula B. Multiply the area of the hole filled by the rivet by the uuinher of rowsof rivets in the seam, and…
Locomotives · Steam-boiler explosions
