own in Figures Nos. i,2, 3 and 4. All of these designs incorporate one most excellent feature, thatwill to a great extent reduce breakages: The gauge glass is inserted in thesplit tube and the top and bottom packing glands set up tightly, before the tubeis inserted into the top and bottom… … Fig. 7.— Revolvable Guard.packing rings are knurled so that they may be screwed up by hand. In makingconnections to the top and bottom fittings on the water cohimn a wrench canbe used with impunity for no strain is put onto the glass by screwing up thepacking nuts. The only essential difference in…
