Kirkman, Marshall M. (Marshall Monroe), 1842-1921 · New York and Chicago, The World railway publishing company · leaf 109
ve-ment in their gauges, thusavoiding the injurious resultsof smoke and gases. STAR NON-CORROSIVE AND NON-SETTINGLOCOMOTIVE STEAM GAUGES. Two styles of these gauges are illustrated by Figs.14 and 15. The former (the standard) knownas the double spring Bourdon type and Fig. 15shows the doublespring… … Fro 14. Star Double-Spring Gauge- -Bourdon Style. LOCOMOTIVE APPLIANCES. 101
Locomotives
