Twentieth century hand-book for steam engineers and electricians with questions and answers; a practical non-technical treatise .. (1913)

Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 449

An illustration from Twentieth century hand-book for steam engineers and electricians with questions and answers; a practical non-technical treatise .., 1913, leaf 449
- to rim of wheel; the innereccentric, marked C, having ears attached, is placed closeto the regulator wheel, and is free to turn upon the shaft;from these ears rods 2, 2 are connected with the weights: … Fig. 159armington and sims shaft governor on the outside of the inner eccentric and free to turn isplaced an eccentric ring D, from which a rod 3 is connectedto the toe of one of the weights; on this outer eccentricring is placed the usual eccentric strap, to which is directlyattached the valve…
