Kirkman, Marshall M. (Marshall Monroe), 1842-1921 · New York and Chicago, The World railway publishing company · leaf 284
b, from where it is possible to oil each bearingsuccessively, or any particular bearing repeatedly,that may be giving temporary trouble by heating. (274) LOCOMOTIVE APPLIANCES. 275 The lubricator is placed, conveniently of access,in the cab (as shown in Fig. 1), and consists of an oilsupply… … Air or Steam Pressure Fig 2.Corys Force Feed Lubricator. conical valve is termed the oil discharge reservoir,and connects to oil supply reservoir by small valve/>, seated in upper part of hollow valve. The side ofthe hollow valve is perforated by a hole, E, one eighthinch diameter, that can be…
Locomotives
