Locomotive breakdown questions answered and illustrated (1907)
Wallace, W. G · Chicago, F. J. Drake & Co. · leaf 157
ngines. Please advise whatthey are, direct or indirect engines. Answer.—Fig. i shows, an inside admission pistonvalve with an indirect rocker. You will observe that the 148 LOCOMOTIVE BREAKDOWN QUESTIONS position of the eccentrics on the shaft or axle is directlyopposite to the position that they… … Fig. J
Locomotives
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
