Locomotive catechism; an up-to-date, practical and complete work on the locomotive--treating on the design, construction, repair and running of all kinds of locomotives .. (1908)
Grimshaw, Robert, 1850- [from old catalog] · New York, The N. W. Henley publishing company · leaf 281
ff. Q. In setting the eccentric crank of the Walschaert gear,from which end of the link should the forward, motion betaken? A. From the lower end; the eccentric crank will follow themain crank for an inside admission valve, and lead it for anoutside valve. Q. Where should the connecting point of… … Fig. 171. The Walschaert Valve Gear. A. Referring to Fig. 171, the eccentric crank, the eccentricrod from this to the link, the radius bar from the lifting link THE WALSCHAERT VALVE GEAR. 275 to the combination lever, the crosshead arm, union linkbetween this and the combination lever, the radius…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
