ith its concavity toward the eccentric. Inthis slot plays accurately a block, which may pass from oneend to the other thereof. This block is attached to the lowerarm by a pin which serves as a pivot.. The two eccentric-rods are attached to the ends of the link by pins serving alsoas pivots. The… … arm borne on a horizontal shaft parallel with the axle. Thislifting-arm, carrying with it the link, may be raised and low- 254 LOCOMOTIVE CATECHISM. ered by a nearly vertical arm, connected by a nearly horizontalreverse rod to a nearly vertical reverse lever in the cab. Mov-ing the upper end of the…
