Locomotive engine running and management : a treatise on locomotive engines, showing their performance in running different kinds of trains with economy and dispatch; also directions regarding the care, management, and repairs of locomotives and all their connections (1888)
Sinclair, Angus, 1841-1919 · New York : J. Wiley · leaf 157
to the delivery-tube D and waste-orifice P, lifts the water through thesupply-pipe into the combining-tube around the hollowspindle, acting after the manner of an ejector or steam-siphon. As soon as solid water issues through thewaste-orifice P, the handle H may be drawn out to itsfull extent,… … Fig. 3. One of the most successful and enduring injectors inuse is the Monitor, the distinguishing feature of whichis, that the injector is constructed with fixed nozzles, INJECTORS. 133 that insure great durability, combined with certainty ofaction. The Monitor injector is shown in section inFig.…
Locomotives
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
