Thermodynamics of the steam-engine and other heat-engines (1889)
Peabody, Cecil Hobart, 1855-1934 · New York, Wiley & Sons · leaf 180
oulder just touches that valve. This smallmotion of the spindle admits steam for raising water till itoverflows at P. When this occurs the spindle is drawn backand the steam-valve X opened wide, upon which the actionshould be complete and water should be forced into the boiler.The rod L is… … Fig. 32.
