rst. Flanged Monitors, Since 1885 the body of the Moni-tor has been divided into two parts, which are firmly INJECTORS, STEAM GAUGES, ETC. 36$ held together by a double flange securely bolted. Thisvery convenient arrangement enables the interior partsto be taken out readily, for cleaning or… … The Figure 167 Monitor, Interior View the spmdle outside the steam chamber, diminishing itswear. The packing can be adjusted and tightened bymeans of a large central nut, still preserving the sim-plicity and convenience of an ordinary stuffing box. The water valve has been provided with a…
