Benjamin, Charles H[enry], 1856- [from old catalog] · New York, H. Holt and company · leaf 193
Fig. 73. Diam. of shaft Diam. of hub Length of hub Diam. ofcoupUng 2 4i 3i 8 2i 5f 4f 10 3 6i 5i 12 3i 8 6i 14 4 9 7 16 5 lU 81 20 172 MACHINE DESIGN There are five bolts in each coupling. The sleeve coupling is neater in appearance than the flangecoupling but is more complicated and expensive. In… … Fig. 74. are prevented from turning by the feather key K and are forcedinto the conical recesses by the two threaded collars CC andthereby clamped firmly to the shaft. The key K also nicksslightly the center of the main sleeve ;S, thus locking the wholecombination. Couplings similar to this have…
Machine design
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
