Benjamin, Charles H[enry], 1856- [from old catalog] · New York, H. Holt and company · leaf 280
y case; for example, if h^ were very greatwhen compared to V, the failure of the joint would probably beby moments about a. The above calculations would be modified,alsp by the arrangement of the bolts or cap screws. It is well in every case to examine a joint from all standpointsand design for the… … Fig. 111. as such the upper end would be as shown in the precedingparagraph. In the larger machines the standard would bemade of wrought iron or steel plates, in which case the sizes ofthe standard and lever end would be calculated from differentvalues of S than those used for cast iron. \ \ The…
Machine design
