Fig. 41. Fig. 42. The angle employed is usually 60 degrees; notice that thecorners c c are clipped for strength and to avoid a corner bearing;notice also the shape of gib. It is better to have the points ofscrews coned to fit gib and not to have flat points fitting recessesin gib. The latter form…
