Benjamin, Charles Henry, 1856- [from old catalog], Hoffman, James David, 1868- [from old catalog] joint author · New York, H. Holt and company · leaf 59
Fig. 9. Fig. 9 shows the three typical forms chosen: (a) Plain sectionwith curved throat; (b) ribbed section with curved throat; (c)plain section with straight throat. All of the specimens wer^small, the depth of gap being only 6 or 7 in. … Table XIII gives the most important results of the experiments.The stress in the last column was calculated by the formula, S = f + ^ (13) the notation being the same as is used elsewhere in this book.1 Pbdc. a. S. M. E., May, 1910. TESTS OF FRAMES 41 TABLE XIII Jenkins Experiments on Riveter…
Machine design
