Benjamin, Charles H[enry], 1856- [from old catalog] · New York, H. Holt and company · leaf 61
Fig. 9. Fig. 9 shows the three typical forms chosen: (a) Plain sectionwith curved throat; (b) ribbed section with curved throat; (c)plain section with straight throat. All of the specimens weresmall, the depth of gap being only 6 or 7 in. … Fig. 10. Table XIII gives the most important results of the experiments.The stress in the last column was calculated by the formula, 8 = f + ^ (13) the notation being the same as is used elsewhere in this book. Proc. A. S. M. E., May, 1910. TESTS OF FRAMES 41 TABLE XIII Jenkins Experiments on…
Machine design
