Benjamin, Charles H[enry], 1856- [from old catalog] · New York, H. Holt and company · leaf 112
Fig. 26. … Fig. 27 88 MACHINE DESIGN. the top of the V should be rounded as a precautionagainst nicks and bruises. The inverted V is preferred for lathes since it willnot catch dirt and chips. It needs frequent lubrica-tion as the oil runs off rapidly. Some lathe carriagesare provided with extensions filled…
Machine design
