Benjamin, Charles H[enry], 1856- [from old catalog] · New York, H. Holt and company · leaf 123
Fig. 41. Fig. 41 shows the spindle of an engine lathe completewith its two bearings. The end thrust is taken by afiber washer backed by an adjusting collar and checknut. Both bearings belong to the class shown inFig. 40. A conical journal with end adjustment is illustrated LUBRICATION. 99 in Fig,…
Machine design
