Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)
Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 140
locating ., ... » , i n ii /. Fig. 107. Diagrammatic Layout for Cone Pulleys the position or the floor holes lor the various kinds of belts, the top only of the floor being shown.In Fig. 108 we have a common open belt. The circles repre-senting the pulleys are drawn, and the belt drawn around them.… … 128 MACHINE DRAWING sent the outer and inner faces of the belt. Next draw the tworectangles which represent the plan view of the pulleys, and drawthrough them the center line RS. From the points E and H, wherethe pitch line intersects the line representing the top of the floor,draw perpendiculars…
