Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)
Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 70
terally, and when so followed becomes a drag onoffice efficiency. A better rule is—Detail every part separatelywhen groups of parts cannot be clearly detailed together. Note on this drawing the method of indicating, by light diagonallines across the shaft, the location of the bearings; also the… … SHAFT ONE-STEEL-F.A.O.Fig. 48. Detail of an Ordinary Shaft Detail of Ordinary Shaft. Fig. 48 shows the detail of an ordi-nary shaft with a number of different bearings and fits upon it. Itillustrates most of the common points which are necessary to bespecified on shaft details. The distance,…
