Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 242
nally, he has made an end view, showingthe relation of the conductors in the slots. Detail Drawing of Coils. He next draws the same set ofcoils to such a scale as will show all necessary detail, Figs. 1, 2, 3,and 4, putting on full and complete dimensions as obtained fromthe design data and the… … 228 MACHINE DRAWING be drawn to a very large scale, such as twice the size, in order thatall dimensions may be shown without sacrificing clearness. Inthis section it should be noted that several diametrical dimensionsare given and that the dimensions of the slot are shown along withthe…
