Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 68
parts together,instead of detailing them separately. It is obvious that the drawingof each detail is just as clear as though it were separately drawn. Infact, the information conveyed is the most complete possible; fornot only are the figures for each part clearly shown, but the exactmanner in…
Machinery
