Machine drawing; a text and problem book for technical students and draftsmen (1921)
Svensen, Carl L. (Carl Lars), 1884- · New York, D. Van Nostrand company · leaf 132
Cam with Point Follower Given the center of the cam, C and the rise of the follower, 04. WithC as a center and radius CO, draw a circle. Divide this circle into threeequal parts by radii CD, and CE. Then divide rise into a number ofequal parts as shown at 1, 2, 3 and 4. Divide arc OD into same…
Machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
