Machinists' and draftsmen's handbook, containing tables, rules and formulas, with numerous examples explaining the principles of mathematics and mechanics as applied to the mechanical trades; intended as a reference book for all interested in mechanical work (1910)
Lobben, Peder, 1858- · New York, D. Van Nostrand company · leaf 389
to the de-signers judgment, but it is a well-known fact that high-speedmachinery must have longer bearings than slow-speed ma-chinery. The length of the bearing will usually vary from one andone-half to six times the diameter. When the shafts are small (less than two inches in diameter),and the… … BEARINGS. 371 Figure 1 shows a cheap, solid cast-iron box used for com-paratively small and less important shafts. Dimensions, suita-ble for bearings from one to two inches in diameter, are givenin the following table :— TABLE No. 45.—Giving Dimensions of Fig. 1. (All Dimensions in Inches.) ^ - ^_…
Mechanical engineering
