A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 286
eam passing through D enters, in I,throvigh de above the piston A and drives it down, whilein II it enters through fg below the piston and drives itup. In the first case, the exhaust steam passes through^/and the exhaust pipe at (9, either into the air or the con-denser; in the second case, it… … slide valve. The steam enters through D, the interior ofthe slide A d, and from it passes, according to its position,above or below the piston by d c or fg. Upon the back ofthe slide there is a pipe A B, open at both ends, of semi-circular cross-section, and fitted steam-tight at A and B to 274…
Mechanics, Applied · Mechanical engineering
