e same as that shown in thedotted rectangle in the center of the 1-inch to the mile mapshown in the right-hand part of the figure. The V.I. of the 6 inches= 1 mile map is 10 feet, that of the 1 inch = 1 mile is 50 feet. Thesemaps serve to shown that practically all of the detail has dis-appeared in… … Fig. 30.—Relation of Scale to Detail. The difficulties of representation on the map, both of hori-zontal and vertical detail, can be learned best by attempting thework in practice. After such practice, the student will be betterprepared to make proper allowance for the inaccuracies…
