Atkinson, Philip. [from old catalog] · New York, The Century co. · leaf 174
rnately, in each series, allaround the field; eight field coils being shown, four ineach series, and four armature coils, the ends of whichare shown. But these relative numbers may vary indifferent motors. ELECTRIC MOTORS. 151 The current from the dynamo traverses each series offield coils… … Fig. 66. entering by G, without reversal, traverses the series con-nected with that terminal, and returns also by A. Thecurrent is then reversed at the dynamo, and the nexttwo successive waves enter by A ; the first turning to theright, traversing the series connected with C and return-ing by that…
Electricity
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
