Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 25

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 25
e bagsare delivered from a car door on to agrating through which the forked handsof the elevator picks them up and dis-charges upon an incHned chute gratingto slide to a horizontal carrier from whichthey are deposited at any desired place.The forked hands are braced loosely tothe sprocket chains,… … by dumping them off the side at places where the inclined guideboard is set.

Mechanical movements
