Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 94
Fig. -Duplex horiiig-inachine. … FiQ. 6.—Cylinder boring-machine. machine has the capacity to bore a 4-in. hole, and receive a pulley 36 in. in diameter, \U-\\\.face, with hub 12 in. in length. It makes three cuts, and finishes by reaming without theremoval of the tools or work. The revolving table is driven by a five-step cone…
Mechanical engineering
