Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 75

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 75
enter cylinder B abovepiston <^ at full pressure, but the crank to cylinder A is on the quarterwhere it moves at its highest speed, while the piston B moves down.It will also be seen that lower piston A reaches the top of its cylinder.At the same time, but instead of being in a position to… … STEAM POWER APPLIANCES. 75
