Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 107

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 107
held in place byan annular follower and springs. 244. BALANCED EXPANSION JOINT for steam pipesSmith pat. Referring to the cut, it will be noticed that the inner tube has an increased diameteror ring about halfwayalong its length. Thisforms a shoulder or pistonat the end next to the bot-tom of the… … STEAM POWER APPLIANCES. I03 .m
