Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 136

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 136
atedfor that purpose, and the pressure of the water upon the diaphragmkeeps it tight against the valve. The larger disk attached to the valvedisk serv^es as a deflector. When the solder is melted, the levers flyapart, and the valve and deflector drop about V^ inch, leaving ,spacefor the water to… … 134 HYDRAULIC POWER AXD APPLIANCES. 2nd TANK STIRRER 1st TANK 3=3 STIRRER 323. DOMESTIC REFRIGERATOR. Water enters the coil atA, and is drawn into the tank at B, in which a quantity of nitrate of ammonia has been placedequal in weight with thewater. The cold pro-duced in the mixturecools the water…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
