Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 204

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 204
shearsthrough a leaden bolt, H, which supports it,and, moving upon its pivot, is forced down thetapering sides which press the sides of the cliptogether so as to grasp the cable very tightly.The greater the strain on the grapnel rope, themore the clips are forced down and the tighterthe cable is… … Lead Bolt 511. STEAM SOUNDING MACHINE. Sigsbee type. - Its prin-cipal parts are the drum, A, on which is wound the wire, the auxiliary pulley, B, used while heaving into relieve drum of the strain, thejockey wheel, C, the swivel pulley,D, the accumulator contained inthe tube, H, and the brake E.…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
