An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 243
e solid on anauxiliary shaft. The variouschanges of speed, as well as thereverse motion, are controlled by one lever or wheel which actuates thecam shaft. All the gears are cut from sohd steel forgings, and are in-closed in an oil-containing aluminum case. It will be noticed from thedrawing that… … 627. DRIVING GEAR FOR A LATHE, change speed gear ontwo vertical shafts beneath the lathe head. The method of connecting motor and spindle is clearly shown. Thearmature shaft is fitted with a bevel pin-ion which drives through bevel reversinggears and a vertical shaft a cone of fivegears which mesh…
