Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 105

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 105
ods at the end of the stroke ofeach piston the dead centre is eliminated. \d d 362. ROOTS SQUARE PISTON EN-GINE.—^The oblong square box, A, is thecylinder proper. B, is a frame sliding freelyin a horizontal direction by the force of thesteam from the side ports, d, d. C is the in-ner rectangular… … 363. DAKE SQUARE PISTONENGINE. — Two rectangular pistons,one within the other, working at rightangles in the outer piston. The innerpiston is connected to the crank pin,and moves vertically. The outer pistonmoves horizontally in the case. Theprinciple is similar to the Root SquareEngine, No. 362.…

Mechanical movements
