Hawkins, N. (Nehemiah), 1833- · New York : Theo. Audel · leaf 322
he passages, I, I, the opposite passage, I, is in communica-tion with the exhaust, J. Suppose that the steam piston has moved to the end of itsstroke, the auxiliary vaKe, which, as stated above, is connectedto the piston rod, is shifted.This releases the steam fromone end of the steam chest,… … Fig. 290. To set the auxiliary valve, remove the pendulum or tappetlever, X, and the cap or bonnet, O, and take out the auxiliaryvalve, E. With a straight edge and scriber indicate the work-ing edges on the end of the valve, and mark the edge of theport on the valve seat so that it can be seen when…
Hydraulic machinery · Pumping machinery
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
