Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 297

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 297
and for giving thepipe the proper form. The lever is pro-.j vided with two grooved wheels pivoted sothat the flanges just clear, thus leaving anopening between the bottoms of thegrooves of the same size and shape as thepipe. The lower wheel is of such size asto give the pipe the proper radius after…

Mechanical movements
