Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 314

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 314
are carriedby small iron wheels, which roll upon the flanges of a pair of channelbeams bolted together and spaced about i inch apart, thus forminga strong truss frame or carrying track capable of spans of consider-able length. At each end the chain passes over a sprocket wheel,and these wheels can… … 809. PATTERN BURRING MACHINE for figured woolen goods.German design, a is a revolving metal brush, under which the stencil plate, h, passes as an endless sheet,guided by the small rollers /, /, g, g.The cloth passes underneath theplate, and has the same speed as thisplate; it is carried forward by…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
