rced to revolve. As the cylinder revolves it presses down upon thestationary ellipse E, and the blade B is forced back into its housing Djust as the blade C is in its housing H at the beginning of the movement.Meanwhile the blade C, which is the duplicate of the blade B, has beencarried around and… … 904. GEOMETRICAL PEN. Suardis type. In the gear pro-portion, as shown, the diameter of a is half of that of A; these wheels are connected by the idler, E, whichmerely reverses the direction with-out affecting the velocity of as rota-tion. The working train arm isjointed so as to pivot about theaxis…
