Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 80

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 80
152. CORLISS EN-GINE. C. & G. Coopertype with double wrist plate.The governor controls theaction of the steam valvesby adjustable trip hooks anddashpots. … 153. CORLISS ENGINE.Hamilton type, with single wristplate and trip-valve gear con-trolled by the governor. The type of most economicalSteam power. 78 STEAM POWER APPLIANCES. 154. CONVERTIBLE COMPOUND ENGINE. Flinn type forautomobiles. Steam enters at the center of the high-pressure steam valve, and…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
