Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 84

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 84
R ArPLTANCES. 8i W^V\V\y^\SSS^ 164. BALANCED PISTON VALVE. The segmental packing,E, is held close to the cylinder wall by the pressure of the steam which enters through holesin the flange, E,shown by the circlesbelow the cylinder.e, live steam connec-tion to receiver oflow-pressure cylin-ders, a…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
