Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 75
Pumps May Be Classified, WithReference To Their Cylinders, as follows: (1) Single orsimplex pumps. (2) Duplex pumps. A simplex pump (Fig.62) has one steam-cylinder and one water-cylinder. Aduplex pump (Figs. 63 and 64) has two steam cylinders andtwo water cylinders. It comprises, in effect, two… … ^^il^^^^fcs; Fig. 62.—Longitudinal Sectional Elevation Of Burnham Direct-Acting Simplex Steam-Pump. -Left-Hanoi Side ,.-Abutments .-■—Piston-Rods jj MgfarTS
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
