171. TYPES OF SLIDE VALVES. Slide valve of the Chandler& Taylor tandem compound engine. The valve is of the gridiron type, and is double-ported for both steam andexhaust, making it possible to admitlarge amounts of steam into each end ofthe cyHnder quickly and with a veryshort valve travel. The… … 84 STEAM POWER APPLIANCES. 172. TYPES OF SLIDE VALVES. Slide valve of the Brownellengine. The valve is of the box type, double-ported for both steam and exhaust, and practically perfectlybalanced. The steam pressure is re-moved from the back of the valve bymeans of a balance ring which bearsagainst…
