177. TYPES OF SLIDEVALVES. Slide valve of theBayley engine. A flat valve ridingunder a balanced pressure plate.Pressure plate is held in place bystays against the steam chest. 178. PARSONS STEAM TURBINE. Steam is admitted at thegovernor valve and arrives at the chamber, A, at the small end of the … revolving part of the turbine. The steam passes along to the rightthrough the turbine blades, passing through a series of fixed bladeswhich deflect it in one direction, thence striking the moving blades of S6 STEAM POWER APPLIANCES. the turbine which deflect it in the opposite direction, and so on.…
