Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 90

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 90
283. Plan showing spring shaft, bearings, lubricating channels and 88 STEAM rOWER APPLIANCES. Steam ducts. Runs by the impact of steam from live nozzles against theouter edge of the buckets of the wheel. The long shaft is to take upthe unbalanced vibration of the disk.
